PONASPRAY 600

600 PSI ECONOMICAL GENERAL PURPOSE

SPRAY HOSE

Agricultural, Pest Control, Lawn, Nursery, & Vineyard Applications
Economical, Lightweight, Flexible, Smooth Interior For Low Friction Loss
Reinforced by High Tenacity Polyester Yarn Braid

NOMINAL SPECIFICATIONS

Nominal Size Outer Diameter Working Pressure Standard Length Approx. Weight
Part Number O
Inch Inch PSI@70 F Ft Lbs/Pkg
B06-025YEN 1/4 0.492 700 300 23.2
COMPARABLE TO K4131 SERIES B06-038YEN 3/8 0.630 700 300/400 32.3/43.0
& SPIRALITE 310 B06-050YEN 1/2 0.787 620 300/400 47.4/63.2
B06-063YEN 5/8 0.945 570 300 68.5
B06-075YEN 3/4 1.102 570 300 82.7

Note: Temperature Range 25 F (-4 C) to 150 F (+65 C) depending on application
O
O
O
O

E-FLEX

ECONOMICAL GENERAL PURPOSE SUCTION

Economical, Light Weight, Flexible, & Durable
Agricultural, Construction, Industrial, & Pumping Scenarios
High Pressure General Material Handling

NOMINAL SPECIFICATIONS
Inner Outer Working Vacuum Bend Standard Approx.
Part Number Diameter Diameter Pressure Rating Radius Length Weight
Clear
O
O
O
Green Clear Inch Inch PSI@70 F In. Hg@70 F In. @70 F Ft Lbs/Ft
* FE2-075GRN FE5-075WHN 3/4 0.97 95 29 2 100 0.13
Green * FE2-100GRN FE5-100WHN 1 1.19 70 29 3 100 0.18
* FE2-125GRN FE5-125WHN 1 1/4 1.46 70 29 3 100 0.24
* FE2-150GRN FE5-150WHN 1 1/2 1.74 65 28 4 100 0.32
FE2-200GRN FE5-200WHN 2 2.30 65 28 6 100 0.55
* FE2-250GRN *FE5-250WHN 2 1/2 2.84 60 28 7 100 0.77
FE2-300GRN FE5-300WHN 3 3.35 60 28 9 100 0.97
COMPARABLE TO 112 AG/112 CL
FE2-400GRN FE5-400WHN 4 4.43 55 28 13 100 1.61
* FE2-500GRN *FE5-500WHN 5 5.43 55 28 20 100 2.11
* FE2-600GRN *FE5-600WHN 6 6.54 55 28 28 100/20 2.92
* FE2-800GRN *FE5-800WHN 8 8.74 28 28 33 25/20 4.92
Note: Temperature Range -4 F (-20 C) to 150 F (+65 C) depending on application
O
O
O
O
* Size available upon request
Ponaflex Hose Manufacturing, Inc. www.ponaflexusa.com
