다호알앤피주식회사

본문 2쪽

About Us Starting with shredders and grinders, DAHO RNP(Recycling & Plant) Co., Ltd is a specialist environmental plant manufacturing and construction company that produces, constructs, and runs facilities for recycling household and industrial waste, as well as logging and forestry waste treatment facilities. We've gained technical mastery since 2006, when we began importing advanced European equipment.

출처: 이 전자책 2쪽

본문 3쪽

Waste Recycling Plant Our company has the plant construction mastery to efficiently crush and sort various wastes such as household waste, business waste, industrial waste, and construction mixed waste. The majority of the waste recycling plant's components, such as shredders, grinders, trommel screens, and wind shifters, are built in-house. We maximize customer economic benefits and satisfaction by configuring facilities to meet specific needs such as with waste characteristics, throughput, installation areas, and operating purpose.

출처: 이 전자책 3쪽

본문 4쪽

Grinder _ DH-500 • Standard Specifications DESCRIPTION SPECIFICATION REMARK PLACE OF ORIGIN REPUBLIC OF KOREA MANUFACTURER DAHORNP. CO., LTD MODEL DH-500 DH-450 TYPE Stationary Grinder Total Length 4.000 mm Full Width 3.800 mm CENTRAL SOURCE Overall Height 4.980 mm Total Weight 29.000 kg Rotor Type Single Shaft Rotor Rotor Length 2.500 mm Rotor Diameter Ø 700 mm GRINDING UNIT Rotor Rotation Speed 350RPM Rotary Blade L100mm x Thickness 30mm, 125pcs Stationary Blade 10pcs Screen Perforation Size 40~85 mm DRIVING DEVICE Power 375kW or 337kW • Throughput 9.0~18 tons/hour (depending on the type…

출처: 이 전자책 4쪽

본문 6쪽

Trommel Screen • Standard Specifications Product Name Trommel Screen Drive Method Size selection by perforated rotary drum Throughput 10 tons/hour POWER Drum 15.0 kW, Lower conveyor 3.7kW Rotational Speed 15~20 RPM Size Ø2,000mm x L6,000mm x H2,200mm (size excluding structures and walkways) Components perforated rotary drum, case, structure • Features Technical collaboration with DOPPSTADT in Germany, utilizing 100% High Technical Skills Korean technological products Manufactured and installed without inclination. Maximize sorting rate Horizontal Drum without reducing input.

출처: 이 전자책 6쪽

본문 7쪽

WIND SHIFTER • Standard Specifications Product Name WIND SIFTER WS 1500 TYPE Separation of light and heavy materials by wind CAPACITY Max 15.0 tons/hr POWER Blower 22.0 kW, Supply Conveyor 3.7kW, Discharge Conveyor 5.5kW, Drum 3.7kW SIZE W2,750mm x L10,000mm x H3,250mm CONTROL METHOD Inverter Control (blast volume) blower, case, air discharge nozzle, waste induction drum, supply conveyor, COMPONENTS discharge conveyor, air internal circulation duct • Features High Technical Skills We produce using our 20 years of technology expertise.

출처: 이 전자책 7쪽

본문 8쪽

METERING FEEDER_ DH-AF-1XXX-E • Standard Specifications PRODUCT NAME STANDARD MATERIAL QUANTITY REMARK Reduction Motor 15~30KW * 4P * 1/30 1 Belt Width 1200~2500 Rubber 1 LOT Belt Thickness 11.5mm 1 Motor RS200 11TB Chain Sprocket S45C 2 Drum RS200 18TB INVERTER Customer-requested Mounting • Features 1. Products used to send waste to the rear sorting equipment in a quantitative manner. 2. With a large-capacity hopper, it is feasible to deal with supply loads more flexibly. 3. Transfer speed can be modified once the inverter is fitted. 4.

출처: 이 전자책 8쪽
