본문 2쪽

SHINEUI is preparing for the future of innovation through continual research and development. We are a company that manufactures and distributes essential functional parts for a wide range of industrial fields. We are a company that is always researching and creating important products for basic industries based on superior technology with the highest quality. In particular, we are prepared to recognize the varied demands of companies related to pressure and flow-related parts and to develop products based on those needs using our bespoke design capabilities and technologies.

출처: 이 전자책 2쪽

본문 3쪽

Flow Sensor Picture Model Specifications Applicable Fluid Drinking Water Operating Range (l/min) 0.2 ~ 1.2 SMWF-015 Allowable Pressure (Max) 10 bar Supply Voltage DC 2.7V ~ 24V Inlet/Outlet Connection Inlet: 1/4”, Outlet: 5/16” Applicable Fluid Drinking Water Operating Range (l/min) 0.05~0.5 SMWF-50CC Allowable Pressure (Max) 10 bar Supply Voltage DC 4.5V ~ 24V / DC 2.7V ~ 24V Inlet/Outlet Connection 1/4” Applicable Fluid Drinking Water Operating Range (l/min) 0.3 ~1.4 / 0.4 ~2.0 / 0.5 ~2.0 SMWF-0420H21/ SMWF-0420H27/ Allowable Pressure (Max) 10 bar SMWF-0420H29 Supply Voltage DC 4.5V ~ 24V…

출처: 이 전자책 3쪽

본문 4쪽

Flow Switch Picture Model Specifications Applicable Fluid Water Flow Operating Point (l/min) ON 2.5 ±0.5 / OFF 2.0 ±0.5 SFS15A/20A Power Specifications DC350V 0.7A , AC300V 0.5A Allowable Pressure 10 bar Inlet/Outlet Connection 15A / 20A Applicable Fluid Water ON 2.5 ±0.5 OFF 2.0 ±0.5 / Flow Operating Point (l/min) ON1.5±0.3 OFF 1.3 ± 0.3 SFS-57/SFS-93 Power Specifications DC100V, AC150V 1A Allowable Pressure 10 bar Inlet/Outlet Connection 15A Pressure Sensor Picture Model Specifications Applicable Fluid Air Pressure Range Standard : 0 ~ 1000 pa SAPSS 5 Power Supply DC 5V, (Optional : 7~20V)…

출처: 이 전자책 4쪽

본문 5쪽

/ PRESSURE SWITCH Variable Gas Pressure Switch Picture Model Specifications Applicable Fluid Standard gas, Air SGPS-xxxV Switching Voltage AC 24V ~ 250V / DC 24V ~ 48V 50V : 2.5 ~ 50 Operating Pressure 150V : 30 ~ 150 (mbar) SGPS-EX-xxxV 500V : 100 ~ 500 Gas Connection PF1/4" (Negative : PF1/8) Variable Air Differential Pressure Switch Picture Model Specifications Applicable Fluid Air Switching Voltage AC 24V ~ 250V / DC 24V ~ 48V SAPS-xxV 3V : 0.4 ~ 3.0 Operating Pressure (mbar) 5V : 0.5 ~ 5 10V : 1 ~ 10

출처: 이 전자책 5쪽

본문 6쪽

Two-Way Valve / Three-Way Valve Picture Model Specifications Applicable Fluid Water Power Supply 220 VAC, 50 /60 Hz STV-300-M Working Pressure 0.2 ~ 3bar Inlet/Outlet Connection 20A , 25A Three-Way Actuator Valve Picture Model Specifications 220VAC Power Supply (Option : 24VAC,110VAC) STV-ACT-LM Push : 4.3sec(60Hz), 5.0(50Hz) 39-75N Operating Hours Rest : 3.7sec(60Hz),4.0(50Hz) Torque 75N , 100N Proportional Control Valve Picture Model Specifications Applicable Fluid Water Power Supply DC 24V , 0.5A MAX Vref (0~10V DC) or PWM (100 ~ STV-200MD-24 Supply Signal 2000 Hz / Duty : 10 ~ 95%)…

출처: 이 전자책 6쪽

본문 8쪽

Address B116-B118, Woorim Lions Building, 283, Bupyeong-daero, Bupyeong-gu, Incheon Comprehensive Consultation Guide +82-32-503-3796 International Sales Department Name Moon, Geon-Mo Name Roh, Ki-Young Quality Assurance Department Name Yim Dong-Yong Research Institute Name Jung, Ik-Seung Sales Department Name Han, Jung-Soo Authorized Retail Store Branch Name Soreunverse

출처: 이 전자책 8쪽
